Spout Pouch SampleApplicable Bag Types
View All Bag Types →Spout Pouch Sample
Spout Pouch SampleProduction Process
Machine Features
1High Speed
- Up to 85-90 straight bags/min and 80-85 angled bags/min
2Wide Spout Range
- Compatible with Φ8-22 mm snap-fit short plastic spouts, with or without cap
3Straight & Angled Spouts
- Handles both straight and 45° angled spout pouches
4Twin Spout Sealing
- Welds 2 plastic spouts simultaneously for higher throughput
Bag SizeStraight‑spout pouch: L×W=(100‑230)×(70‑180) mm
Angle‑cut pouch: L×W=(100‑230)×(70‑150) mm
Angle‑cut pouch: L×W=(100‑230)×(70‑150) mm
Applicable Spout Types① Bayonet‑type, short plastic spout (cap availability customizable)
② Spout diameter Φ8‑22 mm
② Spout diameter Φ8‑22 mm
Corner‑cut Angle45°
Power SupplyAC380V, 50Hz
Total Power9.5 kW
Compressed Air0.6‑0.8 MPa, 360 NL/min
Machine Overall DimensionL×W×H: 4200×1900×1800 mm
Machine Weight2600 Kg
Production EfficiencyStraight‑spout pouch: 85‑90 pcs/min
Angle‑cut pouch: 80‑85 pcs/min
Angle‑cut pouch: 80‑85 pcs/min
NoteProduction efficiency varies with materials and pouch dimensions.
Configurable and optional features (all adjustable per the KQ-2606C design).
